| Code | Optical geometry | Wavelength range |
|---|---|---|
| 5701-D40 | SCI+SCE | 400~700nm |
| 5701-D45 | 45/0 | 400~700nm |


Conforms with CIE No.15, ISO7724-1, ASTM E1164 and DIN5033 Teil7 standards
Grating spectrophotometric, 3.5" IPS full color screen, dual optical path high precise CMOS array sensor
Use long life and low power consumption combined LED light source, include UV and exclude UV measurement
Camera locating function, switchable four apertures
Large capacity storage space, over 20000 measurement data
Two standard observer angles, a variety of illuminant, a variety of color indexes, conforms with a variety of standard colorimetric data
Measure sample spectra, accurate Lab data, can be used in color matching and accurate color transmission
| Code | Optical geometry | Wavelength range |
|---|---|---|
| 5701-D40 | SCI+SCE | 400~700nm |
| 5701-D45 | 45/0 | 400~700nm |
