Shockproof, IP65 dust/waterproof
Can be used to measure length and depth
Reading shows movement value of probe. for example, if probe moves 0.01mm, reading changes 0.01mm
Large working range on three axes (X, Y, Z), which avoids damage of probes due to collision by mistake
| Code | Range | Resolution | Repeatability | X, Y, Z range |
|---|---|---|---|---|
| 2846-3D | ±2mm | 0.005mm | ±0.01mm | 6mm |
